Pressure Compensating Drippers

Provide Uniform Flow Distribution

Pressure Compensating Drippers (PC) developed with advanced pressure compensating technology delivers a uniform flow rate even in areas with difficult topographical conditions. A unique pressure differential mechanism regulates flow and provides self-cleaning action, even while irrigating – for a clog-resistant design and high emission uniformity.

Why Pressure Compensating Drippers?

• Higher and Better Quality Yields: 100% uniformity of water and nutrient delivery over a broad pressure range ensures uniform crop yields and bigger harvests.
• Clogging Resistance: Continuous self-flushing technology ensure consistent flow-rates and flawless operation – even with harsh water.
• Easy to Scale: Number of drippers can be easily increased ensuring sufficient water to meet your crop growth rate requirements.
• Maximum Flexibility: Micro-tubes allow drippers to be positioned exactly where required, and split into several drip outlets if needed.
• Anit-Drain Mechanism (CNL Feature): Eliminates drainage & refill effect, and improves efficiency during pulse irrigation.

Product Advantages

• Patented pressure differential system maintains uniform flow rate at different inlet working pressures (within the recommended range) ensuring exact distribution of water and nutrients.
• Industry’s widest flow path and wider dripper cross-section allow large particles through the dripper’s short flow path.
• Continuous self-flushing system, even while irrigating, provides improved resistance to clogging.
• Ideal for areas with difficult topographical conditions.

Applications

• Vineyards
• Orchards
• Greenhouses and Nurseries

Specifications

• PC and WPC Base Color and Flow (GPH):
  Red 0.53, Black 1.06 and Green 2.11
• PC and WPC (Non-CNL):
  Recommended Operating Pressure: 7 - 58 psi
• WPC (With CNL):
  Recommended Operating Pressure: 14.5 - 58 psi Shut-Off (Closing) Pressure: 2.17 psi (5' of Elevation)
• Recommended Filtration: 120 Mesh
